Truckfridge™

CR65DC 65L/2.29 Cu. Ft 12V Refrigerator w/Freezer

  • Sale
  • Regular price $1,295.00


Description

The CR65DC Truckfridge refrigerator (formerly called the TF65DC)  has been designed and tested to give years of performance and reliability.

The 12V DC power supply makes the Truckfridge especially versatile. The power source can be a battery, a surge protected DC transformer or a solar panel. Note. Never connect the Truckfridge directly to a battery charger. A battery must be used inline to protect the compressor Electric Control Module (ECM).

The CR65DC is a TRUE 12-24VDC compressor refrigerator with freezer.


The high quality components used in the production of the CR65DC result in low power consumption (will not kill your batteries) and higher quality than most OEM refrigerators. The CR65DC is built tough ... built to last ... comes with a two year warranty and uses the world famous Danfoss/Secop compressor for unsurpassed reliability, durability and performance.

The CR65DC comes standard with the "easy-fix system" that consists of bushings through the interior walls of the fridge allowing the customer to mount the fridge without the use of the FLK65 standard 3-piece flange kit. Note. The FLK65 flange kit for the CR65 is included. Use of the FLK65 depends on the type of installtion and customer preference

The refrigerator holds bottles in vertical and horizontal positions. The fan-cooled compressor unit is integrated on the upper part of the refrigerator. Installation frame, adjustable thermostat and interior light are all standard features.

Other Truckfridge models include;

CR49DC (12-24VDC)
CR49ACDC (12-24VDC, 110-220VAC)
TFDR49DC-BL (12-24VDC)

CR65ACDC (12-24VDC, 110-220VAC)
TF86DC (12-24VDC)
CR130DC (12-24VDC)
CR130ACDC (12-24VDC, 110-220VAC)

Product Features

  • TRUE 12Vdc compressor type refrigerator w/freezer for superior performance.
  • High efficiency Danfoss/Secop compressor minimizes power consumption.
  • Super quiet operation.
  • Average power consumption of only 2 amp/hour (40 Amps/24 hours)
  • No power inverter required. Connects directly to the 12V factory wiring in most trucks using appropriate adapter cable.
  • Will not kill your batteries (three level battery protection).
  • Built-in low voltage cut-out and overvoltage protection.
  • Comes standard with the "easy-fix system" and FLK65 Kit for fast and easy installation.
  • Insulation is high density, CFC-free polyurethane foam.
  • Fridge liner is made from thermoformed plastic for easy clean up.
  • Adjustable thermostat and interior light standard.
  • Replaceable texitured matt black front door panel.
  • Reversible door opening.
  • Upgraded interior freezer surround and door.
  • Upgraded door latch provides positive door closure and is also designed with a special catch to allow the door to be secured in the open postion for storage.

Application

Shore Power (110VAC)

The use of shore power eliminates the need for generators, solar power or running the vehicles engine to recharge the auxiliary deep cycle battery during long stop overs..

CR65DC can alternatively be used in shore power applications where 110VAC power is available. Simply add a 12V battery charger always connected to the deep cycle battery. You can plug and unplug the battery charger without affecting the fridge. This is also a very cost effective alternative.

Alternatively, the CR65ACDC eliminates the need for an additional battery charger.

Truck Fridges

The CR65DC is also the ideal built-in refrigerator for highway trucks with sleeper cabs. The CR65DC fits most Freightliner Classic, Peterbilt 379 - 70" sleeper and pre 2009 International with added filler strip. (Cabinet opening should measure approximately 17 3/4” wide).

Van / RV Fridges

The CR65DC is also ideal for many RV and van applications with little or on alterations required and can be installed in Volkswagon Westifia,  Vanagon, Mercedes Sprinter, and Dodge ProMaster vans to name a few.

Specification

Model

CR65DC

Size (HxWxD) inches 21"h x 17 3/4"w x 18 1/2"d
Gross capacity 65 litre / 2.29 cu. ft.
Nominal voltage 12-24 VDC
Nominal input power 60 watt/hour (5 amp/hour)
Average power consumption 40 amps/24 hours at 24C/75F ambient and 2.2C/36F
In-Line Fuse 15A(12VDC), 7.5A(24VDC)
Refrigerant R134a
Temperature Range +2C to -7C (35F to 18F)
Ambient Temperature Indel B Italy claims test to show that unit can maintain food safe temperatures (34-40F / 1-5C) at ambient temperatures up to 120F / 49C.
Air cooling Forced with fan
EMC conformity Yes
Standard Features

Interior light, adjustable thermostat
low voltage cut-out and easy fit system.

Net weight (lbs) 40 lbs
Warranty Two (2) year parts and labour


Note. If in doubt about the model for your truck, always confirm by measuring the height, width and depth of the cabinet opening in your truck.

Please note that models, prices, and availability is subject to change without obligation or notice.

Disclaimer for custom installations* As all good cabinet makers know, never make the first cut on cabinets until you have the appliances in front of you. Screw heads, hinges, and door swings must always be taken into account. Failure to observe this information may result in ill fitting installations or additional costs to you. This is not considered a manufacturing or TruckFridge issue. Specifications may be subject to change without notice or obligation.
