CR49T680 - KW T680/T700 Truck Refrigerator with Freezer

  • Sale
  • Regular price $1,239.00


The CR49T680 is a TRUE 12-24VDC compressor refrigerator with a freezer using the world-famous Danfoss/Secop BD35F-HD heavy-duty compressor for unsurpassed reliability, durability, and performance.

The high-quality components used in the production of the CR49T680 result in low power consumption (will not kill your batteries) and higher quality than most OEM refrigerators. The CR49T680 is built tough ... built to last ... and comes with an unconditional two-year warranty.

The CR49T680 comes standard with the "easy-fix system" that consists of bushings through the interior walls of the fridge allowing the customer to mount the fridge without the use of the TF680/700FK flange kit.

The refrigerator holds bottles in vertical and horizontal positions. The fan-cooled compressor unit is integrated into the upper part of the refrigerator. Installation frame, adjustable thermostat, and interior light are all standard features.

Other Truckfridge models include;

CR49DC (12-24VDC)
CR49ACDC (12-24VDC, 110-220VAC)
TFDR49DC-BL (12-24VDC)

CR65DC (12-24VDC)
CR65ACDC (12-24VDC, 110-220VAC)
CR86DC (12-24VDC)
CR130DC (12-24VDC)
CR130ACDC (12-24VDC, 110-220VAC)

Product Features

  • TRUE 12Vdc compressor type refrigerator/freezer for superior performance
  • High-efficiency Danfoss/Secop compressor minimizes power consumption.
  • Forced air fin and tube condenser for optimal performance.
  • Super quiet Operation.
  • Comes standard with Easy Fix System.
  • Includes TF680/700 installation flange kit at no additional cost. Custom flange kits are available at additional cost.
  • Average power consumption of only 2 amp/hour (40Amp/24Hour)
  • Built-in low voltage cut-out and overvoltage protection.
  • No power inverter is required. Connect directly to the battery.
  • Connects to the 12V factory fridge wiring in your truck using the connector provided.
  • Will not kill your batteries (three-level battery protection)
  • Built-in low voltage cut-out and overvoltage protection.
  • Automatic switching between 12Vdc and 110Vac
  • Installation frame, adjustable electromechanical temperature control thermostat, and interior light standard at no charge.
  • High-density insulation, CFC-free polyurethane foam.
  • The fridge liner is made from thermoformed plastic for easy clean up.
  • Replaceable gloss black front door panel.
  • Reversible door opening
  • Upgraded interior freezer surround and door.
  • Upgraded door latch provides positive closure.
  • 2-year warranty



The CR49T680 is designed to fit the KW T680 and T700 trucks for those who prefer a swing door refrigerator over the OEM drawer refrigerator.




Size (HxWxD) inches 20 1/2"h x 15"w x 18"d
Gross capacity 49 litre / 1.73 cu. ft.
Nominal voltage 12-24VDC
Nominal input power 60 watt/hour (5 amp/hour)
Average power consumption 40 Amps over 24 hours @ 75F/24C ambient with 36F/2.2C internal temperature.
In-line fuse 15A (12VDC), 7.5A (24VDC)
Refrigerant R134a
Temperature Range +2oC to -7oC (35oF to 18oF)
Ambient Temperature Indel B Italy claims test to show that unit can maintain food safe temperatures (34-40F / 1-5C) at ambient temperatures up to 120F / 49C.
Air cooling Forced with fan
EMC conformity Yes
Standard Features

Interior light, adjustable thermostat
low voltage cut-out, easy fit system, and installation flange kit included.

Net weight (lbs) 37 lbs
Warranty Two (2) year parts and labor

Note. If in doubt about the model for your truck, always confirm by measuring the height, width and depth of the cabinet opening before ordering.

Please note that models, prices, and availability is subject to change without obligation or notice.
